OTHER BRAND
Dial Gauge ( 25.50mm ) 0.02 Accuracy Mitutoyo
₹ 1,000 / Piece
Delivery Options
Get delivery at your doorstep
| Graduation | 0.02 mm |
| Accuracy | +-12 Micrometer |
| Measuring Range | 5 mm |
| Brand | Mitutoyo |
| Dial Readng | 0-100 |
| Measuring Force | 1.4 N Or Less |
- Standard 0.02mm graduation dial gauges having an outer frame with an outside diameter of 57mm. All types come with limit pins and an outer frame clamp as standard.
- The outer clamp and lifting lever (optional) can be attached to either the right or left side. These parts can be easily installed and removed without tools.
- Secured adhesion between the outer frame and crystal as well as the use of an O-ring ensure countermeasures against water and oil permeation via the front face.
- The stem spindle is made of high-strength quench-hardened stainless steel which resists strenuous use.
- A carbide contact point is used.
- The grand gear uses stainless steel that is resistant to wear and deformation.
- Application of a hard coating on the surface of the crystal makes the gauge highly scratch- and chemical-resistant
